Descrição
The LR 1000 control is a cost efficient, modular laboratory reactor designed to optimize chemical reaction processes as well as for mixing, dispersing and homogenization tasks on a lab scale particularly in the cosmetic and pharmaceutical industry. The system can be adapted quickly and easily to a wide range of applications and specific requirements.
Prominent features are its intuitive menu navigation, integrated pH and temperature sensor connection as well as several interfaces that allow display and storage of process-relevant data on a PC. By using the laboratory software labworldsoft® (accessory) it is possible to even control the reactor via PC and make further settings. In addition, a control valve connection to attach a magnetic valve (accessory) for program-based cooling water control is integrated.
The medium can be heated either to a fixed maximum temperature of 120 °C or to a set temperature by the heater at the bottom of the vessel. A temperature sensor inside the medium ensures that the set temperature is reached. Both, a PT 100.30 temperature sensor and the corresponding receptacle LR 1000.61 for the lid are included in the delivery.- Components in contact with medium: stainless steel (ALSI 316 L), FFKM, PTFE, PEEK, borosilicate glass 3.3
- Large easy to read TFT display for easy menu navigation
- Integrated control valve connection to attach a magnetic valve (accessory) for program-based cooling water control
- Integrated weighing function
- Torque trend measurement indicates changes in product viscosity
- Integrated pH sensor connection
- RS 232 and USB interface to operate the unit with the laboratory software labworldsoft
- Standard joint fittings on the lid: 2 x NS 29, 2x NS 14, 2 x GL 14 for flexible adaptation of further equipment
- Expandable for use with the ULTRA-TURRAX® T 25 digital (accessory)
- Vacuum valve included in delivery
- Anchor stirrer with PTFE-scrapers
- Connections to attach a cooling source to the back of the unit
- Manual adjustable safety circuit
- Integrated safety shutdown when vessel or lid is removed from the base
Especificação técnica
Volume utilizável máx. 1000 ml Volume min. utilizável com elemento dispersor 500 ml Temperatura de trabalho máx. 120 °C Vácuo alcançável 25 mbar Viscosidade máx. 1000000 mPas ViewReplace 10 Replaced Diâmetro da haste de suporte (com fixação integrada no suporte) 16 mm Material em contato com o meio AISI 316L, 1.4571, vidro borossilicato 3.3, PTFE, PEEK, FFKM Aberturas do frasco do reator (unidades/padrão) 2x NS 29/32, 2x NS 14/23 & 2x GL 14 Tempo LIGADO permissível 100,00% Resolução de medição de temperatura 0.1 K Torque nominal 3 Nm Saída de calor 1000 W Pressão de operação permissível para meio de refrigeração 1 bar Máx. alcance de pesagem 2000 g Resolução de pesagem 1 g Faixa de medição de pH 0 - 14 pH Resolução da medição de pH 0.1 pH Velocidade mín. (ajustável) 10 rpm Temperatura de aquecimento máx. 180 °C Circuito de segurança ajustável 47 - 225 °C Circuito de segurança ajustável, desvio valor de temperatura 10 - 20 ±K Temperatura do meio de refrigeração mín. 3 °C Precisão do controle de calor 1 ±K Precisão de controle com sensor 0.2 ±K Desvio de velocidade 5 ±rpm Display de velocidade TFT Controle de calor TFT Conexão para sensor de temperatura ext. PT 100 Fixação do elemento de agitação eixo de saída especial Display de torque sim Medição de torque tendência Temporizador sim Display do temporizador TFT Controle de velocidade Passos 1 RPM Tipo de refrigeração fluxo Display de temperatura sim Sensor de temperatura de trabalho PT 100 Sensor de temperatura de segurança PT1000 Display de temperatura de trabalho TFT Display de temperatura de segurança TFT Display para operação com sensor ext. sim Disjuntor de segurança sim Interface para MV1 sim Interface para phmetro sim Display valor de pH TFT ViewReplace 50001 Replaced Peso 23 kg ViewReplace 50005 Replaced Umidade relativa permissível 80,00% Classe de proteção de acordo com a DIN EN 60529 IP 21 Interface RS 232 sim Interface USB sim Interface Bluetooth sim Tensão 230 / 115 V Freqüência 50/60 Hz Entrada de alimentação 1200 W -
