Descrição
The new magnetic stirrer RCT 5 digital with 800 W offers significantly more power making it an ideal device for demanding stirring tasks up to 20 l.
Multifunctional menu
Whether determining the direction of rotation, timer functions or sequence programming - the stirring process can be programmed individually from beginning to end. In this way, the reaction runs reliably and safely even without monitoring.
Scratch-resistant ceramic coating
RCT 5 digital has a rectangular set-up plate with a white, ceramic coating. It is less scratch-prone than conventional magnetic stirrer plates.
Safety features
The display is made of chemical resistant and hardened glass which increases the safety of the user. In addition, a symbol in the display warns in case of a hot surface and therefore protects from burnings. The safety circuit can be adjusted up to 370 °C.Especificação técnica
Número de posições de agitação 1 Máx. quantidade de agitação (H2O) 20 l Saída nominal do motor 9 W Direction of rotation right / left Speed display set-value LCD Speed display actual-value LCD Controle de velocidade Turning knob ViewReplace 10 Replaced Configurar velocidade de exatidão 10 rpm Comprimento barra de agitação 30 - 80 mm Auto-aquecimento da placa de aquecimento (RT: 22 ° C / duração: 1h) 13 +K Saída de calor 850 W Temperature display set-value LCD Temperature display actual-value LCD Temperature unit °C / °F ViewReplace 15 Replaced Controle de calor Turning knob Temperature setting range 0 - 310 °C Temperature setting resolution of heating plate 1 K Conexão para sensor de temperatura ext. PT1000, ETS-D5, ETS-D6 Temperature setting resolution of medium 1 K Circuito de segurança ajustável 50 - 370 °C Material da placa configurada Aluminum with ceramic coating Dimensões da placa configurada 137 x 137 mm Automatic reverse rotation sim Intermittend mode sim Medição de tendência de viscosidade sim Temporizador sim Sensor in medium detection (Error 5) sim Speed deviation (no load,nominal voltage, at 1500rpm + 25 °C) 2 ±% Heating rate (1l H2O in H1500) 7.5 K/min Heat control accuracy of heating plate (at 100°C) 5 ±K Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) 0.5 ±K Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) 0.5 ±K Heat control accuracy with ETS-D6 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) 0.2 ±K ViewReplace 50001 Replaced Peso 2.6 kg ViewReplace 50005 Replaced Umidade relativa permissível 80,00% Classe de proteção de acordo com a DIN EN 60529 IP 42 Interface RS 232 sim Interface USB sim Tensão 220 - 230 / 115 / 100 V Freqüência 50/60 Hz Entrada de alimentação 900 W Entrada de alimentação Standby 1.6 W -
